Sovereign

FEATURES

  • High-altitude, heavy-lift, trailer-mounted solution - custom trailer with integrated launch platform and power supply
  • Schutt Industries LTT-Flat-deck Extended trailer or options for commercial/clandestine trailer
  • Optimized for rapid deployment

SPECS

  • Payload: 10-40 lbs (4.5-18.1 kg)
  • Tether length: up to 1,000 ft (304 m)
  • Drone weight: 50 lbs (22.7 kg) without payload
  • Max diameter: 85 in (216 cm)
  • Power required: 3000W 220VAC – 7000W 220VAC depending on payload weight

Contact us for more information.

Systems | Menet Aero

Intrepid

FEATURES

  • Medium lift, with flexible plug & play payload capabilities
  • Program of Record
  • Ethernet & fiber data connections

SPECS

  • Payload: 2-14 lbs (.9-6.4 kg)
  • Tether length: 300 ft (90 m)
  • Drone weight: 16 lbs (7.3 kg) without payload
  • Max diameter: 70 in (178 cm)
  • Power required: 1500W 110VAC – 3500W 220VAC depending on payload weight

Contact us for more information.

Systems | Menet Aero

Independence

FEATURES

  • Ultraportable communications & security
  • 1-person transport & operation - Fits in one 83-lb airline checkable case; complies with MIL-STD-1472G single male lift to 3-ft
  • Flexible payload - Universal MIMO radio payload box accepts MPU5, Streamcaster 4200, TW-950/900; Next-Vision Dragon Eye EO/IR Camera with tracking/targeting
  • May be powered by a portable generator or vehicle inverter

SPECS

  • Payload: 1-2 lbs (.45-.9 kg)
  • Tether length: 200 ft (61 m)
  • Drone weight: 7 lbs (3.2 kg) without payload
  • Max diameter: 46 in (117 cm)
  • Power required: 800W 110VAC – 1200W 110 VAC depending on payload weight

Contact us for more information.

Systems | Menet Aero

Explorer

FEATURES

  • Medium lift, mobile operations drone with fully integrated payloads
  • Land or water vehicle-mounted solution – developed for integration with DoD systems
  • Offering RF over Fiber RX only up to 40GHz (SIGINT); RFoF TX/RX up to 6GHz (Communications); EO/IR camera (Force Protection/Targeting)

SPECS

  • Payload: 2-10 lbs (.8-4.5 kg)
  • Tether length: 300 ft (90 m)
  • Drone weight: 21 lbs (9.5 kg) without payload
  • Max diameter: 70 in (178 cm)
  • Power required: 1500W 110 VAC – 3500W 220VAC (depending on payload weight)
  • Backup power: Backup battery onboard
  • Communication: Secure data/video over tether

Contact us for more information.
